Best Orange5 V1.42 Orange 5 V1.38 Programmer Add More License Full Packet Hardware +Enhanced Function With Full Authorization

Name: Best Orange5 V1.42 Orange 5 V1.38 Programmer Add More License Full Packet Hardware +Enhanced Function With Full Authorization
Brand: obdlaunch
SKU: DIAG-0924-1
Price: 156.55 USD
Availability: InStock

$156.55

~~$0.00~~ $156.55

Sale Sold out

Shipping calculated at checkout.

color V1.42 Full Set V1.42 Main Unit V1.42 Three Adapters V1.38 Full Set V1.38 Main Unit

Ships From CHINA

Product variants

Quantity

Attention:

1.Orange5 ONLY connect via USB power supply 5V voltage. It can not connect external power supply via 12V ,otherwise it will burn, always shows corrupt and kill the board. And Please do not update .

2.Please never try to use higher version or update online, or device will get locked.

Description:

Orange 5 programmer is a professional programming device for memory and microcontrollers. Unique feature of the current series programmers is built-in macro language for writing down protocols, which gives fast and easy capability to add new types of micro schemes, precisely meeting manufacturers' requirements to read/write algorithms.

Orange5 Technical Info

* USB power supply (USB2.0/3.0)

* Universal easy to plug panel ZIF16 for EEPROM

* Control of contacts in the sockets

* Two expansions compatible with Orange4 and Omega MTRK

* Protection against overcurrent

* Overload voltage protection

* Two types of power supply: Standart (USB) and enhanced (USB + external power supply)

* Three 3 adjustable voltage and current control: Voltage of power supply ( 2.0...5.0V ), programming voltage (2.0...21.0V), additional static 10V for microcontrollers

* High-speed bidirectional pin drivers with adjustable voltage (2.0...5.0V)

* Wave cycle generator with frequency ( up to 24 Mhz) and out voltage(2.0...5.0V) adjustment

* Capability of functional emulation of class CDC USB devices

* Built-in 32-bit virtual machine

* Supported interface: I2C, SPI, MicroWire, JTAG, UART, BDM, ISO7816, K-LINE (via adapter), CAN (via adapter)

* Programmer is encolsed in a functional box. Supported working under Windows XP/7 32bit. [*Win8.1]

- Installation and Work with Orange-5 under Windwos 7 and Windows 8.1

CnCterm - Terminal program for work with COM ports.

Feature:

Supports any COM ports, incuding virtual ones from 1 to 20

Works with text (ASCII) and HEX mode

Creating a list of commands that allows editing and fast sending
